9 Channel PoE NVR – MX9104POE
- 9 Channel Network Video Recorder
- 46 Mb incoming bandwidth
- PoE Enabled
- Easily Accessable
- Compact Size
- Latest Technology
System |
|
| Main Processor | ARM Cortex A9 Processor(HI3520D) |
| Operating System | Embedded LINUX |
Video |
|
| Input | 9CH (1920×1080, 1280×960, 1280×720, etc), Incoming Bandwidth: 46MB |
| Output | 1 VGA, 1 HDMI |
Alarm |
|
| Sensor Input | NO |
| Output | NO |
| Motion Detection | 9 Channel |
| Email Alarm | Support |
Display |
|
| VGA | Resolution: 1024×768、1280×720、1280×1024 |
| HDMI | Resolution: 1080P(1920×1080) 720P:(1280×720) |
| Display Split | 9 Channel / 4 Channel / 1Channel |
| Digital Zoom | NO |
| OSD | Camera title, Time, Video loss, Recording, Motion Detection |
Recording |
|
| Video Compression | H.264 |
| Resolution | 1080P(1920×1080) / 960P(1280×960) / 720P(1280×720) / D1 (704×576/704×480) |
| Record Rate | PAL :1080P@225fps, 960P@225fps, 720P@225fps, D1@225fps |
| NTSC:1080P@270fps, 960P@270fps, 720P@270fps, D1@270fps | |
| Record Mode | Manual\Timer\Motion Detection |
Playback & Backup |
|
| Local Sync Playback | 1CH@1080P |
| Remote Sync Playback | YES |
| Search Mode | ALL, Channel, Time, Date, Motion Detection |
| Playback Functions | Play, Pause, Stop, Rewind, Fast play, Slow play |
| Backup Mode | USB Device/Network |
Network |
|
| Interface | 5 x RJ45 (10M/100M Adaptive Ethernet Interface) |
| Network Functions | HTTP, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, FTP, IP Search, P2P |
| Onvif Version | Support Onvif 2.4 |
| Web Browser | IE6-11, Google Chrome (IE Tab), Firefox (IE Tab) |
| CMS Software | Support Windows 7/ Windows 8/Windows 10 |
| Cloud Support(P2P) | Yes |
| POE | 4 x Independent 100Mbps POE Network Interfaces(Output Power≤15.4W per Interface) |
| Smart Phone | iPhone, iPad, Android, Android PAD |
Hard Disk Driver |
|
| Interface Type | 1 SATA Interface ,2.5″/3.5″ SATA |
| Capacity | Up to 6TB capacity |
General |
|
| Language | Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, Farisa |
| German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, korean, Dutch, Greek | |
| USB Interface | 2 USB 2.0 Interfaces |
| Power Supply | DC48V/1250mA ≤10W (Without Hard Disk and POE) |
| Working Environment | -10~55℃/10~90% |
| Dimension(W×D×H) | 215*215*53(mm) |
| Weight | 2.0KG (without HDD) |
